Description

Heat-resistant, high tensile strength hose made of two-ply thermoplastic elastomer (TPE) with coated spring steel spiral and additional axial and radial yarn reinforcement.
This design gives this type of hose unique properties and makes it a versatile, quality product that is particularly suitable for gaseous and liquid media as well as for universal use in medium temperature applications.

  • Properties
  • Length
  • Application Ranges
  • Further Information
  • Superior heat resistance
  • Highly flexible
  • Highly elastic
  • Very high tensile strength
  • Heavy-duty
  • Largely smooth interior
  • Very lightweight
  • Durable/long service life
  • Non-kinking
  • Good oil and gasoline resistance
  • Good resistance to leach and acids
  • Good UV resistance and ozone resistance
  • Smallest bending radii
  • Good chemical resistance
  • Free of plasticizers and halogens
  • Conductive when spiral is grounded
  • Free of cadmium in accordance with BGR 132 (Industry Association Rules 132)
Bestseller besonders zugfest

Standard length: 10 m. Other lengths or diameters on request.

Plant engineering, Suction technology, High-temperature suction, Supply air hoses, Vehicle construction, Filter engine, connecting hose, Feed air intake, car, Transport of hot and cold air, Cold-flexible hoses, Engine fresh air intake, TPE hoses, Air-conditioning and ventilation technology, Elastic hose, highly, Hot air

Wall thickness: 0.6 mm. Axial and radial yarn reinforcement.
Color: black.

Properties

  • Superior heat resistance
  • Highly flexible
  • Highly elastic
  • Very high tensile strength
  • Heavy-duty
  • Largely smooth interior
  • Very lightweight
  • Durable/long service life
  • Non-kinking
  • Good oil and gasoline resistance
  • Good resistance to leach and acids
  • Good UV resistance and ozone resistance
  • Smallest bending radii
  • Good chemical resistance
  • Free of plasticizers and halogens
  • Conductive when spiral is grounded
  • Free of cadmium in accordance with BGR 132 (Industry Association Rules 132)

Length

Standard length: 10 m. Other lengths or diameters on request.

Application Ranges

Plant engineering, Suction technology, High-temperature suction, Supply air hoses, Vehicle construction, Filter engine, connecting hose, Feed air intake, car, Transport of hot and cold air, Cold-flexible hoses, Engine fresh air intake, TPE hoses, Air-conditioning and ventilation technology, Elastic hose, highly, Hot air

Further Information

Wall thickness: 0.6 mm. Axial and radial yarn reinforcement.
Color: black.

Technical specifications

The requested information is available in the spreadsheet.

Spreadsheet

Inner-Ø
(mm)
Outer-Ø
(mm)
Bending radius
(mm)
Pressure
(bar)
Vacuum
(bar)
Weight
(kg/m)
Length
(m)
Price
(€/m)
Article-No.
25 31 25 1,700 0,400 0,187 10 7,78 € 2021025
28 34 28 1,600 0,350 0,210 10 8,02 € 2021028
32 38 32 1,500 0,350 0,240 10 7,72 € 2021032
35 41 35 1,400 0,350 0,263 10 8,43 € 2021035
38 44 38 1,400 0,300 0,280 10 8,72 € 2021038
41 47 41 1,400 0,300 0,310 10 9,03 € 2021041
44 50 44 1,300 0,280 0,330 10 9,33 € 2021044
51 57 51 1,300 0,280 0,380 10 10,02 € 2021051
60 66 60 1,000 0,250 0,450 10 10,92 € 2021060
63 69 63 1,000 0,250 0,470 10 11,22 € 2021063
70 76 70 0,900 0,250 0,525 10 11,93 € 2021070
76 82 76 0,800 0,200 0,570 10 13,76 € 2021076
80 86 80 0,700 0,180 0,600 10 14,23 € 2021080
89 95 89 0,700 0,180 0,670 10 15,25 € 2021089
102 108 102 0,600 0,170 0,770 10 20,42 € 2021102
115 121 115 0,600 0,120 0,860 10 20,04 € 2021115
127 133 127 0,600 0,120 0,950 10 21,34 € 2021127
152 158 152 0,500 0,110 1,140 10 23,84 € 2021150
